Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture

I'm Online Chat Now
Certification
China Hebei Wanchi Metal Wire Mesh Products Co.,Ltd certifications
We are satisfied of your product and thank you for that quality.

—— Alan

I'm the long-term partner of this factory since the product is high quality and security.

—— Smith

The chain link curtain is beautiful and practical, keeping insect outside .

—— Jim

Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture

Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture
Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture

Large Image :  Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture Get Best Price

Product Details:

Place of Origin: Hebei
Brand Name: wanchi
Certification: SGS ISO9001
Model Number: AM-003

Payment & Shipping Terms:

Minimum Order Quantity: 50 square meter
Price: Negotiation
Packaging Details: PP film inside and wooden case outside
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 500+square meter+per week
Detailed Product Description
Material: Stainless Steel Wire 304 Or 316 Rope Construction: 7x7 7x19
Rope Diameter: 1.2mm-3.2mm Aperture: 20mm-200mm
Mesh Type: Knotted Mesh Size: Custom-made
High Light:

stainless steel aviary netting

,

bird aviary wire mesh

Various Kinds Of Colors Flexible Stainless Steel Aviary Mesh Ferruled Mesh





product parameter



Place of Origin Hebei, China (Mainland)
Material tainless Steel Wire
Type Rope Mesh
Application Woven Wire Mesh, Construction of Animal Enclosure,Animal Cage,Aviary
Weave Style Plain Weave
Wire Diameter 1.2MM-3.2MM
Technique Woven
Model Number RM-133
Brand Name wanchi
Wire Rope Construction 7*7,7*19
Opening size 1"x 1", 1-1/2"x1-1/2", 2"x2", 3"x3", and 4"x4"
aviary mesh feature Lightweight, high-strength, never rust, softness





specification



Stainless Steel Rope Mesh
Code structure of wire Wire rope Diameter Aperture Breaking stenght Min.Breaking load (KN) Weight per sqm
inch mm inch mm lbs. KN KG
WCH-3212P/B 7x19 1/8 3.2 4.75 x 4.75 120 x 120 1,600 5.1 0.83
WCH-3210P/B 7x19 1/8 3.2 4 x 4 102 x 102 1,600 5.1 1.02
WCH-3290P/B 7x19 1/8 3.2 3.55 x 3.55 90 x 90 1,600 5.1 1.14
WCH-3276P/B 7x19 1/8 3.2 3 x 3 76 x 76 1,600 5.1 1.35
WCH-3250P/B 7x19 1/8 3.2 2 x 2 51 x 51 1,600 5.1 2.03
WCH-2410P/B 7x7 3/32 2.4 4 x 4 102 x 102 920 2.65 0.57
WCH-2490P/B 7x7 3/32 2.4 3.55 x 3.55 90 x 90 920 2.65 0.64
WCH-2476P/B 7x7 3/32 2.4 3 x 3 76 x 76 920 2.65 0.76
WCH-2460P/B 7x7 3/32 2.4 2.4 x 2.4 60 x 60 920 2.65 0.99
WCH-2450P/B 7x7 3/32 2.4 2 x 2 51 x 51 920 2.65 1.14
WCH-2076P/B 7x7 5/64 2 3 x 3 76 x 76 676 2.55 0.53
WCH-2060P/B 7x7 5/64 2 2.4 x 2.4 60 x 60 676 2.55 0.69
WCH-2050P/B 7x7 5/64 2 2 x 2 51 x 51 676 2.55 0.8
WCH-2038P/B 7x7 5/64 2 1-1/2 x 1-1/2 38 x 38 676 2.55 1.07
WCH-1676P/B 7x7 1/16 1.6 3 x 3 76 x 76 480 1.43 0.34
WCH-1660P/B 7x7 1/16 1.6 2.4X2.4 60X60 480 1.43 0.41
WCH-1650P/B 7x7 1/16 1.6 2 x 2 51 x 51 480 1.43 0.51
WCH-1638P/B 7x7 1/16 1.6 1-1/2 x 1-1/2 38 x 38 480 1.43 0.68
WCH-1630P/B 7x7 1/16 1.6 1.2 x 1.2 30 x 30 480 1.43 0.85
WCH-1625P/B 7x7 1/16 1.6 1 x 1 25.4 x 25.4 480 1.43 1.02
WCH-1250P/B 7x7 3/64 1.2 2 x 2 51 x 51 270 0.7 0.29
WCH-1238P/B 7x7 3/64 1.2 1-1/2 x 1-1/2 38 x 38 270 0.7 0.38
WCH-1230P/B 7x7 3/64 1.2 1.2 x 1.2 30 x 30 270 0.7 0.48
WCH-1225P/B 7x7 3/64 1.2 1 x 1 25.4 x 25.4 270 0.7 0.58
WCH-1220P/B 7x7 3/64 1.2 4/5 X 4/5 20 x 20 270 0.7 0.73

Application



· Animal Enclosure mesh

· animal cages, bird netting

· Agriculture

· Residential

· Sports

· Fall Security

· Ocean Park and other similar environments

· garden decoration and construction and renovation.



Photo Show

Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture 0

Flexible Stainless Steel Bird Mesh High Intensity 20mm - 200mm Aperture 1
