X Tend Stainless Steel Zoo Mesh Flexible Good Perspective Impact Resistance
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Color: | Silver,black | Material: | S-s 304,316,316L |
|---|---|---|---|
| Mesh Type: | Knotted | Mesh Size: | Cuetom-made |
| Rope Construction: | 7*7 7*19 | Aperture: | 20-100mm |
| High Light: | animal enclosure netting,animal enclosure mesh |
||
Good Perspective Flexible X-tend Stainless Steel Zoo Mesh With Material 304 And 316
product details
| Place of Origin | Hebei, China (Mainland) |
| Material | tainless Steel Wire |
| Type | Rope Mesh |
| Weave Style | Plain Weave |
| Wire Diameter | 1.2MM-3.2MM |
| Technique | Woven |
| Model Number | RM-133 |
| Brand Name | wanchi |
| Wire Rope Construction | 7*7,7*19 |
| Opening size | 1"x 1", 1-1/2"x1-1/2", 2"x2", 3"x3", and 4"x4" |
| aviary mesh feature | Lightweight, high-strength, never rust, softness |
product parameter
| Usage | plant climbing wall, zoo mesh |
| Technique | Woven |
| Application | Woven Wire Mesh |
| Hole shape | Square |
| Surface treatment process | polishing |
| Length | Requirement |
| Material | SS 304,316,316L |
| Weave Style | Plain Weave/Twill Weave |
| Color | Silver,Black,etc |
| Type | Weave Wire Mesh |
| wire diameter | 1.2-3.2mm |
| Width | Cunstomized |
| Structure | 7*7 ,7*19 |
The advantage of the stainless steel wire rope mesh
1. The netting is clipped to the cable.
2 .The hole size and diameter can be modified.
3. It can be made to customer orders and statically tested – especially suitable for facades.
4. High strength, strong toughness, free-angles curving and fold, easy for transportation and installment.
5. Anti-corrosive, resist the rust, can be repeated use.
6. Resists chewing by rodents and other pests (tensile strength approximately 100-110,000 PSI)
7.This product can bear the heavy snow and the gale very much.
8. Without toxic material, safety, environmental protection.
specification
| The list of Stainless Steel Wire Rope Mesh (knotted mesh)Material made of S.S 304 or 316 and 316L | ||||||
| Code | Wire Rope Construction | Min. Breaking Load (KN) |
Wire Rope Diameter | Aperture | ||
| Inch | mm | Inch | mm | |||
| YT-3210 | 7x19 | 8.735 | 1/8 | 3.2 | 4" x 4" | 102 x 102 |
| YT-3276 | 7x19 | 8.735 | 1/8 | 3.2 | 3" x 3" | 76 x 76 |
| YT-3250 | 7x19 | 8.735 | 1/8 | 3.2 | 2" x 2" | 51 x 51 |
| YT-2410 | 7x7 | 5.315 | 3/32 | 2.4 | 4" x 4" | 102 x 102 |
| YT-2476 | 7x7 | 5.315 | 3/32 | 2.4 | 3" x 3" | 76 x 76 |
| YT-2450 | 7x7 | 5.315 | 3/32 | 2.4 | 2" x 2" | 51 x 51 |
| YT-2076 | 7x7 | 3.595 | 5/64 | 2.0 | 3" x 3" | 76 x 76 |
| YT-2050 | 7x7 | 3.595 | 5/64 | 2.0 | 2" x 2" | 51 x 51 |
| YT-2038 | 7x7 | 3.595 | 5/64 | 2.0 | 1.5" x 1.5" | 38 x 38 |
| YT1676 | 7x7 | 2.245 | 1/16 | 1.6 | 3" x 3" | 76 x 76 |
| YT-1650 | 7x7 | 2.245 | 1/16 | 1.6 | 2" x 2" | 51 x 51 |
| YT-1638 | 7x7 | 2.245 | 1/16 | 1.6 | 1.5" x 1.5" | 38 x 38 |
| YT-1625 | 7x7 | 2.245 | 1/16 | 1.6 | 1" x 1" | 25.4 x 25.4 |
| YT-1250 | 7x7 | 1.36 | 3/64 | 1.2 | 2" x 2" | 51 x 51 |
| YT-1238 | 7x7 | 1.36 | 3/64 | 1.2 | 1.5" x 1.5" | 38 x 38 |
| YT-1225 | 7x7 | 1.36 | 3/64 | 1.2 | 1"x1" | 25.4x25.4 |
| YT-1220 | 7x7 | 1.36 | 3/64 | 1.2 | 4/5"x4/5" | 20x20 |
