Stainless Steel Rope Net Black Oxidized 40*40mm Stainless Steel Cable Mesh
Staineless steel rope net instruction:
Stainless steel wire rope mesh is composed of 304, 304L, 316, 316L process is divided into hand-woven, closed mouth, open buckle.Assembled by stainless steel wire rope with 100% seamless rope ferrule. Optimal stretch at 60°angle.easily install by special border design.
Wire diameter:1.0-4.0mm(Customized)1.2mm,1.5mm,2.0mm,2.5mm,3.2mm,4mm
Opening :20-300mm(Centre distance)
Stainless steel material :
| Table 1: Wire Rope Ferrule Mesh Material Composition Table |
| Type |
C (%) |
Si (%) |
Mn (%) |
Cr (%) |
Ni (%) |
S (%) |
P (%) |
| 304 |
≤ 0.07 |
≤ 1.0 |
≤ 2.0 |
17.0–19.0 |
8.0–11.0 |
≤ 0.03 |
≤ 0.035 |
| 304L |
≤ 0.03 |
≤ 1.0 |
≤ 2.0 |
17.0–19.0 |
8.0–12.0 |
≤ 0.03 |
≤ 0.035 |
| 316 |
≤ 0.08 |
≤ 1.0 |
≤ 2.0 |
16.0–18.5 |
10.0–14.0 |
≤ 0.03 |
≤ 0.035 |
| 316L |
≤ 0.03 |
≤ 1.0 |
≤ 2.0 |
16.0–18.0 |
12.0–15.0 |
≤ 0.03 |
≤ 0.045 |
Buckle type
Generally, there are two types of buckle: one is closed-type buckle and the other is open-type buckle.
Features of closed type: the mesh has multiple steel wire ropes combined together, and the closed buckle is relatively stronger, but there are multiple joints at one end of the closure.
Open-type features: the whole mesh can be made with a steel wire rope, which is convenient for installation and has a beautiful overall effect.
The application of stainless steel rope mesh
1. Steel Mesh Balustrade - bridge, stair, balcony, path
2. Cable Mesh - Excellent Solution to Safety
3. Safety Net - Structural Measure to Prevent Suicide
4. Helipad Safety Net - Modular Heliport Webbing
5. Cable Zoo Mesh - Solution to Enclosing Most Animals
6. Aviary Netting - Lightweight, Durable and Long Lasting
7. Green Facade - Cable System for Most Climbing Plants
