PVC Coated Rope Net Fence 316L Stainless Steel Wire Mesh Panels

500 square meter
MOQ
20$ per square meter
Price
PVC Coated Rope Net Fence 316L Stainless Steel Wire Mesh Panels
Features Gallery Product Description Request A Quote
Features
Specifications
Product: Rope Mesh Fence
Keyword: Rope Net Fence
Material: Stainless Steel 304
Wire Diameter: 1.0mm
Mesh Size: 50cm*50cm
Color: Green
Application: Rope Mesh Fence
Feature: Easy Installation
Panel Size: 2m*10m
Warranty: 5 Years
Highlight:

rope net fence 316l

,

316l stainless steel wire mesh panels

,

pvc coated rope net fence

Basic Infomation
Place of Origin: China
Brand Name: Yuhan Wiremesh
Certification: SGS.BV
Model Number: YH-007
Payment & Shipping Terms
Packaging Details: Wooden Pallet
Delivery Time: 10 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 square meter per week
Product Description

PVC Coated Light Weight 316L Rope Net Fence With 1.5mm Wire





1,About the rope mesh fence instruction:



Wire rope ferrule mesh, also known as cable ferrule mesh or stainless steel ferrule rope mesh, is made of 304, 304L, 316 or 316L stainless steel materials. It combines both flexibility and stability and has a high strength-to-weight ratio, which fully reflects the super-toughness and plasticity of austenitic stainless steel.

inch mm inch mm
7 × 19 5/32" 4.0 3" × 3"
7 × 19 5/32" 4.0 3.6" × 3.6"
7 × 19 5/32" 4.0 4" × 4"
7 × 19 5/32" 4.0 5" × 5"


2,Stainless steel material details:



Table 1: Wire Rope Ferrule Mesh Material Composition Table
Type C (%) Si (%) Mn (%) Cr (%) Ni (%) S (%) P (%)
304 ≤ 0.07 ≤ 1.0 ≤ 2.0 17.0–19.0 8.0–11.0 ≤ 0.03 ≤ 0.035
304L ≤ 0.03 ≤ 1.0 ≤ 2.0 17.0–19.0 8.0–12.0 ≤ 0.03 ≤ 0.035
316 ≤ 0.08 ≤ 1.0 ≤ 2.0 16.0–18.5 10.0–14.0 ≤ 0.03 ≤ 0.035
316L ≤ 0.03 ≤ 1.0 ≤ 2.0 16.0–18.0 12.0–15.0 ≤ 0.03 ≤ 0.045


3, Rope Mesh Fence advantages:


 Easy assembly and durability.The wire ropes are securely fixed with ferrules, making the assembly process become simple. Stainless steel material offers high load-bearing capacity,relatively low weight, and high tensile strength.

Flexible structure and easy packaging & transportation.It can be easily bent and folded without compromising its strength, safety, or other characteristics. Besides, it can be flexibly installed and rolled into small packages for transportation.

Excellent corrosion resistance & weather resistance.We offer stainless steel ferrule rope mesh made of 304, 304L, 316, and 316L materials. Their exceptional weather resistance makes them an ideal choice for outdoor applications.

Unique design.Each mesh can be designed and manufactured according to your specific project requirements. Rope diameter, opening size, and mesh aperture size can be customized, allowing for various design possibilities for designers.


4, Advantage of ferruled connection rope net fence:



Wire rope ferrule mesh, also known as cable ferrule mesh or stainless steel ferrule rope mesh, is made of 304, 304L, 316 or 316L stainless steel materials. It combines both flexibility and stability and has a high strength-to-weight ratio, which fully reflects the super-toughness and plasticity of austenitic stainless steel.



PVC Coated Rope Net Fence 316L Stainless Steel Wire Mesh Panels 0
