Attribute | Value |
---|---|
Product Name | Rope Mesh |
Material | AISI 304 or 316 |
Cable Diameter | 1.6MM |
Manufacturer | SS Rope Mesh Co., Ltd. |
Durability | High |
Mesh Size | 27mm |
Dimensions | 20m (Length) × 20m (Width) |
Color | Silver |
Our stainless steel rope mesh, also known as cable ferrule mesh, is crafted from premium 304, 304L, 316 or 316L stainless steel materials. This innovative architectural solution combines exceptional flexibility with structural stability, offering an outstanding strength-to-weight ratio that showcases the superior toughness and plasticity of austenitic stainless steel.
Closed-Type Buckle: Features multiple steel wire ropes combined together for enhanced strength, with multiple joints at the closure end.
Open-Type Buckle: Constructed from a single continuous steel wire rope for easier installation and a seamless aesthetic appearance.
Wire Rope Diameter (D) | Mesh Aperture (M) |
---|---|
5/32" (4.0mm) | 3" × 3" |
5/32" (4.0mm) | 3.6" × 3.6" |
5/32" (4.0mm) | 4" × 4" |
